Why you ask? Well, beyond the fact that it is fast, lightweight and ultra-capable on all sorts of terrain, it’s just damned good lookin’. Short-travel trail bike? “Lowcountry” rig? Occasional race bike? Whatever, call it what you want to call it. All we know is that this is one hell of a mountain bike.
Having an integrated shock allows us to improve this in several ways. Firstly, the frame construction around the shock and with the trunnion mount can be designed to be much more rigid, reducing movement and fostering more efficient power transfer. We can also add much larger bearings to the seat tube pivot, further reinforcing this area and reducing any unnecessary motion. Our integrated Suspension technology also helps us to engineer frames with a lower shock placement which lowers the centre of gravity. As a result, the bike benefits from better handling, and a more stable, confidence-inspiring ride for the end-user.
Key Features & Benefits:
- Adjustable Head Angles:With the new Spark, you can adjust the head angle by .6 degrees slacker or steeper. This can be done without cutting cables or bleeding brakes. All you must do is disassemble the bar, rotate the headset cups 180 degrees, and reassemble.
- Integrated Suspension System:For the optimal performance of a suspension shock, power transfer must be the most direct possible. What we want to avoid are any inefficient directional movements, in other words, lateral movements (sideways to the direction of travel) as the shock goes through its compression.
- Sram 12 speed: Reliable, with a wide range of gears for all-terrain – even the biggest of hills.
Full Specification:
- Frame:Spark Alloy SL 6011Integrated Suspension Technology Flex Pivot / Adjustable head angle Syncros Cable Integration System BB92 / UDH Interface / 12x148mm with 55mm Chainline
- Rear Shock:X-Fusion NUDE 5 RLX Trunnion SCOTT custom w. travel / geo adj. 3 modes: Lockout-Traction Control-Descend Reb. Adj.Travel 120-80-Lockout / T165X45mm
- Fork:RockShox Judy Silver TK Solo Air 15x110mm QR axle / 42mm offset / Tapered Steerer 2-Modes / Reb. Adj. / Lockout / 130mm travel
- Number of Gears:12
- Gear Shifters:SRAM SX Eagle Trigger
- Chainset:SRAM SX Eagle DUB55mm CL
- Chainrings:32T
- Rear Cassette:SRAM SX-PG1210 / 11-50 T
- Chain:SRAM CN SX Eagle
- Rear Derailleur:SRAM NX Eagle 12 Speed
- Bottom Bracket:SRAM DUB PF 92 MTB Wide / shell 41x92mm
- Pedals:Not supplied:
- Rims:Syncros X-30SE / 32H / 30mm
- Front Hub:Formula CL-811 / 15x110mm
- Rear Hub:Formula CL-3248 / 12x148mm
- Front Tyre:Schwalbe Wicked Will 29×2.4″ Performance / TLR / Addix
- Rear Tyre:Schwalbe Wicked Will 29×2.4″ Performance / TLR / Addix
- Brakes:Shimano MT201 Disc
- Handlebars:Syncros Fraser 2.0 DC Alloy 6061 D.B.mini Rise / back sweep 8° / 760mm
- Handlebar Grips: Syncros Pro lock-on grips
- Headset:Syncros – Acros Angle adjust & Cable Routing HS System +-0.6° head angle adjustment ZS56/28.6 – ZS56/40 MTB
- Stem:Syncros DC 3.0Syncros Cable Integration System0° rise / 6061 Alloy / 31.8mm / 1 1/8″
- Saddle:Syncros Tofino 2.5 Regular
- Seatpost:Syncros Duncan Dropper Post 2.531.6mm / S & M size 130mm / L & XL size 150mm
- Weight:14,95 kg
